Technical Specifications

• Max measurement range:                          ≥500m

• Fundamental frequency accuracy:             ≤0.01Hz

• Deformation measurement accuracy:        ≤0.1mm

• The Number of monitoring points:            ≥30

• Deformation data update rate:                  ≥200Hz

• Weight:                                                       ≤1kg

• Fundamental frequency range:                  0-25Hz

• Power consumption:                                  ≤5W

Main Features

• The system features long detection range, with deflection and frequency measurement accuracy remaining consistent regardless of distance.

• Requiring no reflective targets on measured objects, it enables simultaneous multi-span or multi-point measurements of bridges or buildings, offering rapid deployment and low cost.

• Built on edge computing architecture, it performs onboard data processing with automatic transmission to host computers or servers, while storing results for offline data recovery when network connection is interrupted.

• Supports both automatic and manual selection of monitoring points.

• Equipped with real-time atmospheric disturbance compensation algorithms, it ensures minimal data drift during long-term operation.

• The device is able to simultaneously measure multiple cables (up to 30) with high efficiency.

• The device can automatically filter out abnomal frequency results and deliver reliable fundamental frequency estimation.
